NT100
Leantall
100T
Technical Parameter
Part | Name | Unit | 100 | ||
Injection Unit
| SCREW DIAMETER | mm | 30 | 32 | 35 |
SCREW L/D RATIO | L/D | 23.5 | 22 | 20 | |
INJECTION STROKE | mm | 165 | 165 | 165 | |
NJECTION SPEED | Mm/sec | 88 | 88 | 88 | |
SHOT VOLUME(THEORETICAL) | CM3 | 117 | 133 | 158 | |
INJECTION WEIGHT(PS) | g | 106 | 121 | 144 | |
INJECTION PRESSURE | Mpa | 230 | 203 | 170 | |
INJECTION RATE | cm³/sec | 62 | 70 | 84 | |
SCREW SPEED | rpm | 181 | |||
Clamping Unit
| CLAMP FORCE | Kn | 1000 | ||
OPEN STROKE | mm | 320 | |||
SPACE BETWEEN TIE BARS | mm×mm | 360X360 | |||
MAX.MOULD HEIGHT | mm | 350 | |||
MIN.MOULD HEIGHT | mm | 150 | |||
EJECTOR STROKE | mm | 90 | |||
EJECTOR FORCE | Kn | 30 | |||
EJECTOR NUMBER | N | 5 | |||
Others
| MAX.PUMP PRESSURE | Mpa | 16 | ||
SEVRO DRIVE POWER | Kw | 11 | |||
HEATING POWER | Kw | 7 | |||
MACHINE DIMENSION(L*W*H) | m×m×m | 4.2*1.2*1.8 | |||
MACHINE WEIGHT(ESTIMATE) | T | 3.1 | |||
MARKET
FAQ
Q: What is the product range?
A: Focus on the manufacturing and developing plastic injection molding machines and their auxiliary equipment such as robot arms, cooling towers, chillers, etc.
Q: Will you offer field installation and operator training at the buyer's factory?
A: Yes, we will arrange our skilled engineers for field installation and training.
Q: What is the delivery time(equipment production time)?
A: It will be ready around 50 days after getting mutual confirmation about the order details and prepayment.
Q: Do you also have the source for molds and spare parts?
A: Yes, we can offer competitive quality and reasonable prices. Customized as required.
Q: What is the standard of the package?
A: Wooden case packing for the auxiliary equipment, and bare packing for the plastic injection molding machine. Full container shipment is highly suggested.
