You need a space-saving solution for small-part production. Introducing the 180 ton compact vertical injection molding machine, designed specifically for spoons and other small plastic utensils. Its vertical design takes up less floor space, while its precision ensures every spoon is molded perfectly. Whether you’re producing disposable cutlery or high-end kitchenware, this machine fits your needs. Let’s dive into its benefits.
| Quantity: | |
|---|---|
NT180
Leantall
180T
Part | Name | Unit | 180 | ||
Injection Unit
| SCREW DIAMETER | mm | 42 | 45 | 50 |
SCREW L/D RATIO | L/D | 21.4 | 20 | 18 | |
INJECTION STROKE | mm | 225 | 225 | 225 | |
NJECTION SPEED | Mm/sec | 94 | 94 | 94 | |
SHOT VOLUME(THEORETICAL) | CM3 | 312 | 358 | 442 | |
INJECTION WEIGHT(PS) | g | 284 | 326 | 402 | |
INJECTION PRESSURE | Mpa | 218 | 190 | 154 | |
INJECTION RATE | cm³/sec | 130 | 149 | 184 | |
SCREW SPEED | rpm | 210 | |||
Clamping Unit
| CLAMP FORCE | Kn | 1800 | ||
OPEN STROKE | mm | 435 | |||
SPACE BETWEEN TIE BARS | mm×mm | 525X465 | |||
MAX.MOULD HEIGHT | mm | 550 | |||
MIN.MOULD HEIGHT | mm | 180 | |||
EJECTOR STROKE | mm | 129 | |||
EJECTOR FORCE | Kn | 46 | |||
EJECTOR NUMBER | N | 5 | |||
Others
| MAX.PUMP PRESSURE | Mpa | 16 | ||
SEVRO DRIVE POWER | Kw | 22 | |||
HEATING POWER | Kw | 9.9 | |||
MACHINE DIMENSION(L*W*H) | m×m×m | 5.4*1.4*2.3 | |||
MACHINE WEIGHT(ESTIMATE) | T | 5.4 | |||
You might ask: How does vertical design help with spoon production? Vertical machines have a top-to-bottom layout, with the mold opening vertically. This is ideal for small parts like spoons, which often use gravity to eject parts automatically. The compact size—up to 30% smaller than horizontal machines—lets you fit it in tight spaces, perfect for small factories or workshops.
You don’t have room for large equipment. Our 180-ton vertical machine has a footprint of just [X] m², making it easy to install in limited spaces. The vertical mold stack also means you can add automated pick-and-place systems without extra floor space.
Spoons require smooth curves and thin handles. The machine’s high-precision screw and low-pressure injection system ensure even material distribution, preventing defects like thin spots or sink marks. The temperature-controlled mold keeps plastic cool quickly, so each spoon has a glossy finish and consistent shape.
You might produce different spoon designs. The intuitive control panel lets you adjust parameters for handle length, bowl size, or material type (PP, PS, or biodegradable plastics). Quick mold changes—thanks to the vertical clamp—mean you can switch between designs in minutes, ideal for small runs or custom orders.
Here’s the step-by-step: Plastic pellets melt in the horizontal barrel, then the screw injects the molten plastic into the vertical mold from the side. The 180-ton clamp holds the mold shut as the plastic cools. When the mold opens vertically, gravity helps the spoons fall onto a conveyor belt or collection tray—no need for complex ejector systems. You get clean, defect-free spoons, fast and efficiently.
Produce thousands of disposable spoons daily with minimal waste. The machine’s efficiency and small size make it ideal for high-volume, low-margin production.
For premium spoons with intricate designs, the precision molding ensures details like logos or patterns are sharp and clear. The vertical design also reduces stress on handles during ejection, preventing breakage.
Beyond spoons, use it for forks, knife handles, or small components like bottle caps. The compact size and versatility make it a smart investment for any small-part production.
You don’t need a large machine to make high-quality spoons. Our 180-ton compact vertical injection molding machine offers space efficiency, precision, and ease of use—everything you need for spoon production. Whether you’re a small business or a large manufacturer, it fits your workflow and budget. Upgrade today and see how a compact design can boost your productivity without compromising on quality.
