| Quantity: | |
|---|---|
NT200
Leantall
200T
Designed for space-constrained environments, the 200 Ton Compact Vertical Plastic Injection Molding Machine redefines efficiency in cup production with its vertical clamping design, occupying 60% less floor space than equivalent horizontal models. This compact powerhouse excels in producing single and multi-wall cups with precise wall thickness control (0.2-2mm) and intricate surface detailing, making it perfect for small-to-medium scale manufacturers and high-mix production scenarios.
Eliminates horizontal mold alignment issues through gravity-assisted part ejection, reducing mold wear by 40% and improving tool life by 200+ hours.
Enables simultaneous injection and ejection in multi-cavity molds, increasing output by 30% for complex cup designs (e.g., double-wall insulated cups with handles).
Integrates a 6-axis robotic arm with vision-based quality inspection, capable of sorting 150 cups per minute by size, color, or defect status.
Counterbalanced injection unit and rubber-mounted base reduce floor vibrations to <5μm, critical for maintaining dimensional accuracy in thin-walled containers.
Manufacturing hot/cold drink cups, smoothie bowls, and promotional event cups with UV-resistant additives for outdoor use.
Producing stackable measuring cups, leak-proof travel mugs, and modular kitchen storage containers with snap-fit lids.
Creating chemical-resistant specimen cups for laboratories, featuring tamper-evident seals and barcode-readable surfaces.
In-house tooling department specializing in vertical mold design, offering rapid prototyping (7-day turnaround) for unique cup profiles (tapered, square, or hexagonal shapes).
Advanced regenerative braking system recovers 20% of energy from hydraulic deceleration, lowering electricity costs by $0.05 per 1000 cups produced.
Intuitive 12-inch HMI with recipe storage (up to 100 product settings) and one-click startup, reducing operator training time to less than 2 hours.
Part | Name | Unit | 200 | ||
Injection Unit
| SCREW DIAMETER | mm | 45 | 50 | 55 |
SCREW L/D RATIO | L/D | 22.2 | 20 | 18.2 | |
INJECTION STROKE | mm | 250 | 250 | 250 | |
NJECTION SPEED | Mm/sec | 103 | 103 | 103 | |
SHOT VOLUME(THEORETICAL) | CM3 | 397 | 490 | 594 | |
INJECTION WEIGHT(PS) | g | 361 | 445 | 540 | |
INJECTION PRESSURE | Mpa | 221 | 179 | 148 | |
INJECTION RATE | cm⊃3;/sec | 163 | 202 | 244 | |
SCREW SPEED | rpm | 225 | |||
Clamping Unit
| CLAMP FORCE | Kn | 2000 | ||
OPEN STROKE | mm | 435 | |||
SPACE BETWEEN TIE BARS | mm×mm | 480X480 | |||
MAX.MOULD HEIGHT | mm | 550 | |||
MIN.MOULD HEIGHT | mm | 180 | |||
EJECTOR STROKE | mm | 135 | |||
EJECTOR FORCE | Kn | 46 | |||
EJECTOR NUMBER | N | 5 | |||
Others
| MAX.PUMP PRESSURE | Mpa | 16 | ||
SEVRO DRIVE POWER | Kw | 30 | |||
HEATING POWER | Kw | 12.5 | |||
MACHINE DIMENSION(L*W*H) | m×m×m | 5.4*1.45*2.1 | |||
MACHINE WEIGHT(ESTIMATE) | T | 5.5 | |||
