NT900
Leantall
900T
Technical Parameter
Part | Name | Unit | 900 | ||
Injection Unit
| SCREW DIAMETER | mm | 95 | 100 | 105 |
SCREW L/D RATIO | L/D | 22 | 21 | 20 | |
INJECTION STROKE | mm | 470 | 470 | 470 | |
NJECTION SPEED | Mm/sec | 84 | 84 | 84 | |
SHOT VOLUME(THEORETICAL) | CM3 | 3331 | 3691 | 4069 | |
INJECTION WEIGHT(PS) | g | 3031 | 3358 | 3702 | |
INJECTION PRESSURE | Mpa | 189 | 171 | 155 | |
INJECTION RATE | cm³/sec | 595 | 659 | 727 | |
SCREW SPEED | rpm | 120 | |||
Clamping Unit
| CLAMP FORCE | Kn | 9000 | ||
OPEN STROKE | mm | 1100 | |||
SPACE BETWEEN TIE BARS | mm×mm | 1125X1085 | |||
MAX.MOULD HEIGHT | mm | 1100 | |||
MIN.MOULD HEIGHT | mm | 500 | |||
EJECTOR STROKE | mm | 335 | |||
EJECTOR FORCE | Kn | 216 | |||
EJECTOR NUMBER | N | 17 | |||
Others
| MAX.PUMP PRESSURE | Mpa | 16 | ||
SEVRO DRIVE POWER | Kw | 45+45 | |||
HEATING POWER | Kw | 48.5 | |||
MACHINE DIMENSION(L*W*H) | m×m×m | 11.3*2.65*3.4 | |||
MACHINE WEIGHT(ESTIMATE) | T | 40 | |||
MARKET
FAQ
Q: What is the product range?
A: Focus on the manufacturing and developing plastic injection molding machines and their auxiliary equipment such as robot arms, cooling towers, chillers, etc.
Q: Will you offer field installation and operator training at the buyer's factory?
A: Yes, we will arrange our skilled engineers for field installation and training.
Q: What is the delivery time(equipment production time)?
A: It will be ready around 50 days after getting mutual confirmation about the order details and prepayment.
Q: Do you also have the source for molds and spare parts?
A: Yes, we can offer competitive quality and reasonable prices. Customized as required.
Q: What is the standard of the package?
A: Wooden case packing for the auxiliary equipment, and bare packing for the plastic injection molding machine. Full container shipment is highly suggested.
