| Quantity: | |
|---|---|
NT200
LEANTALL
8477101090
A complete range of injection molding machines offers manufacturers a diverse selection of equipment designed to handle different types of materials, part complexities, and production volumes. These machines provide a solution for virtually every need in industries ranging from automotive and consumer electronics to medical devices and packaging.
General-Purpose Injection Molding Machines: These versatile machines are capable of handling a wide range of thermoplastic materials like ABS, PVC, PP, PE, and PET. They are ideal for mass production of standard components used across multiple industries, such as consumer products, automotive parts, and toys.
Precision Injection Molding Machines: For industries that require high levels of accuracy and consistency, such as aerospace, medical devices, and electronics, precision machines offer tight tolerances and micrometric control over the injection process.
High-Speed Injection Molding Machines: These machines are designed for fast, high-volume production and are often used in industries where cycle times need to be minimized, such as in packaging (for bottles and containers), medical components, and automotive parts.
Specialized Injection Molding Machines: Some industries have very specific requirements that call for specialized molding solutions. For example, machines for molding PET bottles, paint barrels, or thin-walled parts. These machines are tailored to handle particular materials and achieve the necessary results for unique product types.
Versatility: A wide range of machines ensures that manufacturers can find the best fit for their specific production needs, whether it's a small batch of custom parts or a high-volume run of standardized products.
Flexibility: The ability to switch between different types of materials and molding techniques makes these machines versatile across various industries. For example, a machine capable of both single-color and multi-color injection molding can adapt to various product design requirements.
Cost-Effectiveness: Having access to the right machine for each production requirement means manufacturers can optimize their operations and reduce material waste and production costs. A complete range of machines helps manufacturers scale their operations efficiently as demand grows.
A comprehensive selection of injection molding machines allows businesses to choose the best equipment for their specific needs, maximizing productivity and reducing manufacturing costs.
Technical Parameter | |||||
Part | Name | Unit | NT200 | ||
Injection unit | SCREW DIAMETER | mm | 45 | 50 | 55 |
SCREW L/D RATIO | L/D | 22.2 | 20 | 18.2 | |
SHOT VOLUME(THEORETICAL) | CM3 | 397 | 490 | 594 | |
INJECTION WEIGHT(PS) | g | 361 | 445 | 540 | |
INJECTION PRESSURE | Mpa | 221 | 179 | 148 | |
INJECTION RATE | cm⊃3;/sec | 192 | 237 | 287 | |
PLASTICZATION CAPACITY(PS) | g/sec | 26 | 36 | 48 | |
INJECTION STROKE | mm | 250 | |||
INJECTION SPEED | Mm/sec | 121 | |||
SCREW SPEED | rpm | 210 | |||
Clamping unit | CLAMP FORCE | Kn | 2000 | ||
OPEN STROKE | mm | 460 | |||
SPACE BETWEEN TIE BARS | mm×mm | 520X480 | |||
MAX.MOULD HEIGHT | mm | 550 | |||
MIN.MOULD HEIGHT | mm | 200 | |||
EJECTOR STROKE | mm | 129 | |||
EJECTOR FORCE | Kn | 61 | |||
EJECTOR NUMBER | N | 5 | |||
Others | MAX.PUMP PRESSURE | Mpa | 16 | ||
PUMP MOTOR POWER | Kw | 29 | |||
HEATING POWER | Kw | 9.9 | |||
MACHINE DIMENSION(L*W*H) | m×m×m | 5.4*1.4*2.1 | |||
MACHINE WEIGHT(ESTIMATE) | T | 5.4 | |||
1. Q: What is the product range?
A: Focus on the manufacture and development of plastic injection molding machines and its auxiliary equipment such as cooling tower, chiller, etc.
2. Q: Where is your main selling market?
A: We have business domestic, USA, Russia, Indonesia, Egypt, Turkey, Uzbekistan, Pakistan, etc.
3. Q: Will you offer field installation and operator training at the buyer's factory?
A: Yes, we will arrange our skilled engineers for filed installation and training.
4. Q: What is the delivery time(equipment production time)?
A: It will be ready around 50-75 days after getting mutual confirmation about the order details and prepayment.
5. Q: Do you also have source for molds and spare parts?
A: Yes, we can offer with the competitive quality and reasonable price. Customized as required.
6. Q: What is the standard of package?
A: Wooden case packing for the auxiliary equipment, bare packing for the plastic injection molding machine. Full container shipment is highly suggest.
