As manufacturers increasingly focus on sustainability, environmental injection molding machines are designed to reduce environmental impact while still delivering high performance. These machines focus on energy efficiency, recycling, and reducing emissions, helping manufacturers meet environmental regulations and corporate sustainability goals.
Energy Efficiency: Many modern machines feature energy-saving technologies, such as variable-speed drives and high-efficiency motors, to reduce electricity consumption.
Reduced Carbon Footprint: These machines often incorporate systems that minimize emissions and use materials that can be recycled, helping to reduce the environmental impact of the manufacturing process.
Eco-Friendly Materials: Environmental injection molding machines are designed to handle bio-based and recycled plastics, supporting the move toward circular economies in plastics production.
Packaging: Eco-friendly packaging solutions made from recycled plastics and biodegradable materials.
Automotive: Production of lightweight, sustainable parts for vehicles, contributing to lower carbon emissions.
Consumer Products: Sustainable production of eco-friendly consumer goods made from recycled and recyclable materials.
Environmental injection molding machines play a crucial role in helping companies meet their sustainability goals while continuing to produce high-quality products.
Technical Parameter | |||||
Part | Name | Unit | NT750 | ||
Injection unit | SCREW DIAMETER | mm | 95 | 100 | 105 |
SCREW L/D RATIO | L/D | 23 | 22 | 21 | |
SHOT VOLUME(THEORETICAL) | cm3 | 3260 | 3612 | 3983 | |
INJECTION WEIGHT(PS) | g | 2966 | 3286 | 3624 | |
INJECTION PRESSURE | Mpa | 175 | 158 | 143 | |
INJECTION RATE | cm⊃3;/sec | 758 | 840 | 926 | |
PLASTICZATION CAPACITY(PS) | g/sec | 132 | 152 | 189 | |
INJECTION STROKE | mm | 460
| |||
INJECTION SPEED | Mm/sec | 107
| |||
SCREW SPEED | rpm | 125 | |||
Clamping unit | CLAMP FORCE | Kn | 7500 | ||
OPEN STROKE | mm | 1000 | |||
SPACE BETWEEN TIE BARS | mm×mm | 1020X970 | |||
MAX.MOULD HEIGHT | mm | 960 | |||
MIN.MOULD HEIGHT | mm | 390 | |||
EJECTOR STROKE | mm | 340 | |||
EJECTOR FORCE | Kn | 212 | |||
EJECTOR NUMBER | N | 21 | |||
Others | MAX.PUMP PRESSURE | Mpa | 16 | ||
PUMP MOTOR POWER | Kw | 44+44 | |||
HEATING POWER | Kw | 46 | |||
MACHINE DIMENSION(L*W*H) | m×m×m | 10.6*2.24*2.65 | |||
MACHINE WEIGHT(ESTIMATE) | T | 35 | |||
1. Q: What is the product range?
A: Focus on the manufacture and development of plastic injection molding machines and its auxiliary equipment such as cooling tower, chiller, etc.
2. Q: Where is your main selling market?
A: We have business domestic, USA, Russia, Indonesia, Egypt, Turkey, Uzbekistan, Pakistan, etc.
3. Q: Will you offer field installation and operator training at the buyer's factory?
A: Yes, we will arrange our skilled engineers for filed installation and training.
4. Q: What is the delivery time(equipment production time)?
A: It will be ready around 50-75 days after getting mutual confirmation about the order details and prepayment.
5. Q: Do you also have source for molds and spare parts?
A: Yes, we can offer with the competitive quality and reasonable price. Customized as required.
6. Q: What is the standard of package?
A: Wooden case packing for the auxiliary equipment, bare packing for the plastic injection molding machine. Full container shipment is highly suggest.
