NT320
LEANTALL
8477101090
CLAMPING UNIT
INJECTION UNIT
As we look for ways to reduce labor costs and increase productivity, Labor-Saving Injection Molding Machines have become increasingly popular. These machines are equipped with automation systems that reduce the need for manual intervention during production.
Robotic Arms: Installed on the machine for runner or product grab automatically. Improve automation and reduce personnel loss and reducing the need for human operators in the post-molding phase.
Automatic Mold Adjustments: Advanced machines are capable of adjusting mold settings automatically, based on the material and product specifications, minimizing setup time and human error.
High Integration: Integrated control systems that manage various operations such as injection speed, pressure, and cooling, all automatically, reduce the time and labor involved in manual adjustments.
Mass Production: Automotive, electronics, and packaging industries benefit from labor-saving systems, allowing them to produce high volumes of parts with minimal human intervention.
Medical Devices: Automation ensures precision and consistency, critical for medical products.
Technical Parameter | |||||
Part | Name | Unit | NT320 | ||
Injection unit | SCREW DIAMETER | mm | 60 | 65 | 70 |
SCREW L/D RATIO | L/D | 21.6 | 20 | 18.5 | |
SHOT VOLUME(THEORETICAL) | CM3 | 848 | 995 | 1154 | |
INJECTION WEIGHT(PS) | g | 771 | 905 | 1050 | |
INJECTION PRESSURE | Mpa | 176 | 150 | 129 | |
INJECTION RATE | cm⊃3;/sec | 302 | 355 | 412 | |
PLASTICZATION CAPACITY(PS) | g/sec | 48 | 63 | 76 | |
INJECTION STROKE | mm | 300 | |||
INJECTION SPEED | Mm/sec | 107 | |||
SCREW SPEED | rpm | 180 | |||
Clamping unit | CLAMP FORCE | Kn | 3200 | ||
OPEN STROKE | mm | 620 | |||
SPACE BETWEEN TIE BARS | mm×mm | 660X625 | |||
MAX.MOULD HEIGHT | mm | 630 | |||
MIN.MOULD HEIGHT | mm | 230 | |||
EJECTOR STROKE | mm | 160 | |||
EJECTOR FORCE | Kn | 101 | |||
EJECTOR NUMBER | N | 13 | |||
Others | MAX.PUMP PRESSURE | Mpa | 16 | ||
PUMP MOTOR POWER | Kw | 39 | |||
HEATING POWER | Kw | 18.5 | |||
MACHINE DIMENSION(L*W*H) | m×m×m | 6.45*1.65*2.35 | |||
MACHINE WEIGHT(ESTIMATE) | T | 9.0 | |||
1. Q: What is the product range?
A: Focus on the manufacture and development of plastic injection molding machines and its auxiliary equipment such as cooling tower, chiller, etc.
2. Q: Where is your main selling market?
A: We have business domestic, USA, Russia, Indonesia, Egypt, Turkey, Uzbekistan, Pakistan, etc.
3. Q: Will you offer field installation and operator training at the buyer's factory?
A: Yes, we will arrange our skilled engineers for filed installation and training.
4. Q: What is the delivery time(equipment production time)?
A: It will be ready around 50-75 days after getting mutual confirmation about the order details and prepayment.
5. Q: Do you also have source for molds and spare parts?
A: Yes, we can offer with the competitive quality and reasonable price. Customized as required.
6. Q: What is the standard of package?
A: Wooden case packing for the auxiliary equipment, bare packing for the plastic injection molding machine. Full container shipment is highly suggest.
